Low Insertion Loss 0.9mm 1X2 Optical Switch

The 1x2 optical switch is connected to the optical path by connecting or blocking the optical signal, the product is controlling by electrical signal to switch the optical path, the excellent design makes the product have the advantages of high stability, high reliability, low loss and low cost, which are widely used in the switching and protection of optical network.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Features:

Low Insertion Loss
Wide Wavelength Range
Low Crosstalk
High Stability, High Reliability
Latching and Non-latching

Application:

Sub-system Integration
Optical Network Monitoring/Protection
Route Fiber Test System
Re-configurable OADM
Test & Measurement Equipment Manufacturing Application
Network Test System

Pins Defining		Optical Route	Electricity driving				Condition Monitoring
Control model		1×2	1	5	6	10	2-3	3-4	7-8	8-9
Latching	Bar	P1-P2	--	--	GND	V+	Close	Open	Open	Close
Latching	Cross	P1-P3	V+	GND	--	--	Open	Close	Close	Open
Non-latching	Bar	P1-P2	--	--	--	--	Close	Open	Open	Close
Non-latching	Cross	P1-P3	V+	--	--	GND	Open	Close	Close	Open
